Impact
protectors

Preventing damage
is easy.
more

Highly resistant fastening systems

Indumetal impact protectors guarantee a very high resistance to impacts also thanks to the fastening system included in the supply. The protectors are fixed into the ground with special sleeves with an internal thread (M10 - M12 - M16) joined with chemical anchors by injection. The installation requires drilling the hole, cleaning it, applying the chemical anchor, inserting the sleeve with an internal thread and, once this has hardened, the protector is fixed with the screws provided.

Model: M10 | Ø HOLE mm: 18 | T HOLE mm: 115
Model: M12 | Ø HOLE mm: 22 | T HOLE mm: 130
Model: M16 | Ø HOLE mm: 28 | T HOLE mm: 175



Surface finishes

For the outdoor area:
Basic galvanisation. High-quality scratch-resistant painting with thermosetting powders in UV-resistant polyester in yellow RAL 1023, with black reflective diagonal stripes at 45°, or in white RAL 9010, with red reflective diagonal stripes at 45°.

For the indoor area:
High-quality scratch-resistant painting with thermosetting powders in polyester in yellow RAL 1023, with black diagonal stripes at 45°, or in white RAL 9010, with red diagonal stripes at 45°.

Special solutions

Tailored solutions for specific requirements
For all cases outside of the ordinary, where generally used safety structures are not the best solution, our company studies and implements tailored solutions. In these cases, working with an industrial structure that has resolved many similar cases is an additional advantage for the client.
